Minimum Order Quantity: 2 pieces
Preis: CN¥10,699.05/pieces >=2 pieces
private mold: |
NO |
products status: |
Stock |
type: |
Rack |
processor main frequency: |
2.8GHz |
processor type: |
Intel xeon |
model number: |
SR650 V3 |
place of origin: |
Beijing, China |
Model NO.: |
SR650 V3 |
Form Factor: |
2U rack server |
Processor: |
Two or four third-generation Intel Xeon Scalable processors, |
Memory: |
Up to 48 DIMM slots (12 DIMMs per processor). |
Memory maximums: |
Up to 12TB with 48x 256GB 3DS RDIMMs and four processors |
Maximum internal storage: |
368.64TB using 24x 15.36TB 2.5-inch NVMe SSDs |
GPU support: |
Supports up to 8x single-wide GPUs or up to 4x double-wide GPUs |
Power supply: |
750W/1100W/1800W |
Weight: |
Maximum: 62 kg (137 lb) |
Warranty: |
3years |
private mold: |
NO |
products status: |
Stock |
type: |
Rack |
processor main frequency: |
2.8GHz |
processor type: |
Intel xeon |
model number: |
SR650 V3 |
place of origin: |
Beijing, China |
Model NO.: |
SR650 V3 |
Form Factor: |
2U rack server |
Processor: |
Two or four third-generation Intel Xeon Scalable processors, |
Memory: |
Up to 48 DIMM slots (12 DIMMs per processor). |
Memory maximums: |
Up to 12TB with 48x 256GB 3DS RDIMMs and four processors |
Maximum internal storage: |
368.64TB using 24x 15.36TB 2.5-inch NVMe SSDs |
GPU support: |
Supports up to 8x single-wide GPUs or up to 4x double-wide GPUs |
Power supply: |
750W/1100W/1800W |
Weight: |
Maximum: 62 kg (137 lb) |
Warranty: |
3years |
Form / Höhe | 2U-Rack-Server |
Verarbeiter | Bis zu 2 3rd Generation Intel ® xeon ® Skalierbarer Prozessor Platin-Serie, bis zu 40 Kerne, bis zu 270W TDP |
Gedächtnis | Speicher: 32 DDR4-Speichersteckdosen; Verwenden Sie 32 128GB 3ds-Rdimms; Bis zu 16 Intel ® Ao Teng TM Permanent Memory 200-Serie-Modul |
Antriebsraum | Bis zu 20 3,5 Zoll oder 40 2,5 Zoll Antriebe; bis zu 32 nvme-Antriebe, unterstützt durch nvme-Schalteradapter; 2 m.2 Boot-Antriebe (RAID 1); Rücken End 2 7mm-Startantriebe (RAID 1) |
Erweiterungsslots | Der Erweiterungsslot unterstützt bis zu 10 PCIe-Slots, darunter 8 PCIe 4.0-Slots, 1 OCP 3.0-Slot und 1 HbA / raid Adapter-Slot mit Kabel (gilt nicht für PCIe-Standard-Slots) |
Netzwerkoberfläche | Lom-Adapter ist in OCP 3.0-Slot installiert; mehrere PCIe-Adapter können gleichzeitig unterstützt werden |
Stromversorgung | Doppel redundante Stromversorgung (maximal 1800 W Platin) |
Systemmanagement | Lenovo XClarity-Controller |
Unterstützung von GPUs | Bis zu 8 GPUs mit einer einzigen Breite oder 3 GPUs mit zwei Breiten |
USB-Anschluss | Vorderseite: 1 USB 3.1 G1, 1 USB 2.0, unterstützt xclarity mobile, 1 VGA (optional), 1 externer Diagnosetelefonanschluss Rücken: 3 USB 3.1 G1, 1 VGA, 1 RJ-45 (Management), 1 serieller Port (optional) |
HBA / Raid Unterstützung | Standard-Software RAID; optional Hardware-Raid mit / ohne Cache oder 8 / 16 Port SAS HBA |
